Hammer Track Ti

Framesets start at $3,700

Completes start at $6,450

Start Your Build

The Hammer Track Ti takes everything we've learned from building bikes the last 10+ years. It's our most light weight, yet most durable track frame.

We designed it with just enough vertical flex to eat the road and pump out of turns while maintaining lateral stiffness for predictive steering and mean sprints. It is a race worthy machine. The Track Ti has a modern track geometry that reduces toe overlap while increasing high speed maneuverability and stability.

Each frame is handmade in our Brooklyn workshop with aerospace grade titanium. We employ a mix of traditional hand techniques and digital fabrication to create a truly advanced and one of a kind frame.


Lifetime Warranty

We stand behind the work we do here, a titanium bike is a lifetime bike. All of our Ti creations come with a lifetime warranty.

Optional Integrated Seat Mast

We are offering this frame in ISP and standard seatpost configurations. For those of you that want the added stiffness and clean look of an integrated seat mast we can make that happen. If you want the ease of travel and adjustability of a standard seatpost, that’s fine too.

Seamless 3/2.5 Tubing

Seamless tubing butted, cut and formed in house to your specifications

3D Printed 6/4 Titanium

The ability to 3D print in titanium allows us to create a lighter, stiffer and more customizable, frame with the clean visual lines our machines are known for.

Under Mount Rear Brake Option

If you want a rear brake or your local laws require it, we offer an under mount rear brake option to preserve the sleek look of track frame.

Make It Your Own

Each frame we build is designed specifically for you. Every finish we create is unique, so your bike is one of one. We will work with you to help bring your dream bike to life.

  • Specifications:

    -Seamless 3Al-2.5V Titanium Tubing

    -Weis Signature Internal Topper with 25 mm Up/Down Adjustment

    -3D Printed 6/4 Titanium NDS Dropout With Internal Lattice Structure

    -Integrated Bearing Headtube

    -Double Pass TIG Welded Construction

    -30c Tire Clearance (depending on rim width)

    -BSA Bottom Bracket

    -Frame Weight: 1.25 kg (Size 54)

  • What's Included:

    -Lifetime Warranty

    -Ceramic Bead Blasted Frame With Anodized Logos

    -Weis Signature Sealed Bearing Headset

    -Weis Signature Internal Topper or Seat Collar

    -Front Brake Compatible

    -Full Carbon Tapered Fork

    -Weis Signature Top Cap
 Frame Size 49 52 54 56 58 60
Head Tube Angle 73 73.5 73.5 73.5 73.5 73.5
Seat Tube Angle 75.5 75 74.5 74.5 74.5 74.5
Top Tube (Effective) 500 530 550 570 580 600
Seat Tube 490 520 540 560 575 595
Head Tube Length 105 125 140 161 169 183
Chainstay Length 390 390 390 390 390 390
BB Drop 52 52 52 52 52 52
Fork Rake 43 43 43 43 43 43
Axle To Crown 370 370 370 370 370 370
Stack 495 513 531 549 559 570
Reach 370 391 391 417 424 436
