Hammer Track Ti

Framesets start at $3,700

Completes start at $6,450

Start Your Build

The Hammer Track Ti takes everything we've learned from building bikes the last 10+ years. It's our most light weight, yet most durable track frame.

We designed it with just enough vertical flex to eat the road and pump out of turns while maintaining lateral stiffness for predictive steering and mean sprints. It is a race worthy machine. The Track Ti has a modern track geometry that reduces toe overlap while increasing high speed maneuverability and stability.

Each frame is handmade in our Brooklyn workshop with aerospace grade titanium. We employ a mix of traditional hand techniques and digital fabrication to create a truly advanced and one of a kind frame.


Lifetime Warranty

We stand behind the work we do here, a titanium bike is a lifetime bike. All of our Ti creations come with a lifetime warranty.

Optional Integrated Seat Mast

We are offering this frame in ISP and standard seatpost configurations. For those of you that want the added stiffness and clean look of an integrated seat mast we can make that happen. If you want the ease of travel and adjustability of a standard seatpost, that’s fine too.

Seamless 3/2.5 Tubing

Seamless tubing butted, cut and formed in house to your specifications

3D Printed 6/4 Titanium

The ability to 3D print in titanium allows us to create a lighter, stiffer and more customizable, frame with the clean visual lines our machines are known for.

Under Mount Rear Brake Option

If you want a rear brake or your local laws require it, we offer an under mount rear brake option to preserve the sleek look of track frame.

Make It Your Own

Each frame we build is designed specifically for you. Every finish we create is unique, so your bike is one of one. We will work with you to help bring your dream bike to life.

  • Specifications:

    -Seamless 3Al-2.5V Titanium Tubing

    -Weis Signature Internal Topper with 25 mm Up/Down Adjustment

    -3D Printed 6/4 Titanium NDS Dropout With Internal Lattice Structure

    -Integrated Bearing Headtube

    -Double Pass TIG Welded Construction

    -30c Tire Clearance (depending on rim width)

    -BSA Bottom Bracket

    -Frame Weight: 1.25 kg (Size 54)

  • What's Included:

    -Lifetime Warranty

    -Ceramic Bead Blasted Frame With Anodized Logos

    -Weis Signature Sealed Bearing Headset

    -Weis Signature Internal Topper or Seat Collar

    -Front Brake Compatible

    -Full Carbon Tapered Fork

    -Weis Signature Top Cap
 Frame Size 49cm 52cm 54cm 56cm 58cm 60cm
Head Tube Angle 73° 73.5° 74° 74° 74° 74°
Seat Tube Angle 75.5° 75° 74.5° 74.5° 74.5° 74.5°
Top Tube Length(Effective) 500mm 530mm 550mm 570mm 580mm 600mm
Seat Tube Length(C-C) 490mm 520mm 540mm 560mm 575mm 595mm
Head Tube Length 106mm 128mm 140mm 159mm 169mm 183mm
Chainstay Length 390mm 390mm 390mm 390mm 390mm 390mm
BB Drop 52mm 52mm 52mm 52mm 52mm 52mm
Fork Rake 43mm 43mm 43mm 43mm 43mm 43mm
Axle To Crown 372mm 372mm 372mm 372mm 372mm 372mm
Stack 495mm 518mm 531mm 549mm 559mm 572mm
Reach 371mm 390mm 403mm 417mm 425mm 441mm
