The Hammer Track Steel started it all. It’s our original race proven machine. Our modern track geometry combined with the ride of steel makes a frame that is stable and predictable at high speeds yet agile and confident through turns.
It features our extra stiff Weistec drive side, and a hand selected mix of Italian Steel - Columbus Life, Zona and Spirit tubing. A tapered head tube and full carbon tapered fork to top it off and you end up with an all around race bike, at home in criteriums, track races or city shredding. Steel is real!
Modern Track Geometry
We took our knowledge and experience of bicycle design and revisited what it means to race and ride track bikes in this day and age. Our modern track geo maintains the aggressive and agile feel of a track machine and combines it with high speed stability and confidence.
Integrated Bearing Headtube
We designed a headtube to elevate steel as a frame material. Instead of unsightly external bearings, our headtube integrates high quality sealed bearings and houses an oversized and tapered carbon fork for confident and responsive steering.
Steel Is Real
Your frame is made from a hand-selected mix of high quality Columbus steel and Weis signature tubes.
Custom Select Tubing
We design our frames from the ground up. We carry a large selection of tubing to adapt to every customer and riding style. When we say custom we mean it, no one frame is the same.
Under Mount Rear Brake Option
If you want a rear brake or your local laws require it, we offer an under mount rear brake option to preserve the sleek look of track frame.
Make It Your Own
Each frame we build is designed specifically for the customer. We do not duplicate paint jobs, so your bike is one of one. We will work with you to help bring your dream bike to life.
-
Specifications:
-Columbus Steel Tubing
-Precision TIG Welded Construction
-Weis Signature Die Formed Tubing Profiles
-CNC Machined Tapered Headtube
-27.2 Seatpost Size
-Weistec Rear Triangle
-Clears 30c Tires (depending on rim width)
-BSA Bottom Bracket
-Front Brake Compatible Fork
-Frame Weight: 1.55 kg (Size 54)
-
What's Included:
-Frameset With Choice Of
One Base Color + Logo Color
-Weis Signature Headset
-Weis Signature Seat Collar
-Front Brake Compatible
-Full Carbon Tapered Fork
| Frame Size | 49cm | 52cm | 54cm | 56cm | 58cm | 60cm |
| Head Tube Angle | 73° | 73.5° | 74° | 74° | 74° | 74° |
| Seat Tube Angle | 75.5° | 75° | 74.5° | 74.5° | 74.5° | 74.5° |
| Top Tube Length(Effective) | 500mm | 530mm | 550mm | 570mm | 580mm | 600mm |
| Seat Tube Length(C-C) | 490mm | 520mm | 540mm | 560mm | 575mm | 595mm |
| Head Tube Length | 104mm | 127mm | 140mm | 161mm | 167mm | 181mm |
| Chainstay Length | 390mm | 390mm | 390mm | 390mm | 390mm | 390mm |
| BB Drop | 52mm | 52mm | 52mm | 52mm | 52mm | 52mm |
| Fork Rake | 43mm | 43mm | 43mm | 43mm | 43mm | 43mm |
| Axle To Crown | 372mm | 372mm | 372mm | 372mm | 372mm | 372mm |
| Stack | 494mm | 516mm | 529mm | 548mm | 557mm | 570mm |
| Reach | 371mm | 391mm | 403mm | 417mm | 425mm | 442mm |
